Description
Product Description
The incredible new Akiles FlexiPunch-M manual interchangeable die binding punch offers the ability to switch punching styles in seconds without the huge price tag that accompanies most other modular binding punches. The new FlexiPunch-M can be used for plastic comb binding, double loop wire binding or for spiral coil binding. This make the FlexiPunch an ideal solution for an office that needs to use multiple binding styles or for an organization that wants the flexibility to change in the future. One die set is included with the FlexiPunch-M and additional dies are available for purchase seperately. Just make sure that you remember to buy a coil inserter, comb opener or wire closer to help finish your bound documents.
Product Details
- High Volume Punching Capacity: The heavy duty manual punching mechanism can handle up to 25 sheets of 20lb paper per lift.
- Interchangeable Die Sets: You can easily change from one punching pattern to another. No tools are required and it only takes seconds to switch patterns.
- Fully Disengageable Punching Pins: The FlexiPunch-M allows punching of all paper sizes without partially punched holes at either end.
- Four Available Punching Patterns: Punching patterns are available for comb punching (rectangular holes), 2:1 pitch twin loop wire binding (square holes), 3:1 pitch twin loop wire binding (square holes) and 4:1 Pitch (0.2475") Round Hole Coil Binding.
- Adjustable Depth of Punch Margin Control: Available for all four punching dies, this feature allows you to adjust the distance of the punched holes from the edge of your document.
- Twelve Inch Punching Length: The 12" punching length of this document enables easy punching of both letter size or A4 sized documents. You can even punch larger sheet sizes utilizing the open throat design of this machine..
- Heavy-Duty All Metal Construction: The FlexiPunch-M features a heavy-duty all metal construction, including heavy cast side plates and non-skid feet.
- Weight: 24 Lbs
- Warranty: 1 Year Manufacturer Warranty
Item Specifications
- Model: FlexiPunch-M
- Available Die Sets: Plastic Comb Binding (19 hole rectangular), 2:1 Pitch Wire (square holes), 3:1 Pitch Wire (square holes), 4:1 Pitch Coil (0.2475 Pitch Round Holes)
- Operation: Manual
- Punch Capacity: Up to 25 sheets of 20 lbs paper
- Punch Length: Twelve inch punching length with open ends for longer sheets
- Fully Disengageable Pins: Yes (on all die sets)
- Adjustable Depth Margin: Yes (4-step adjustment)
- Machine Dimensions:14.75" L x 20.5" W x 21.25" H (machine with handle)
- Die Set Dimensions:16.5" L x 4.75" W x 6.75" H (die set)
- Machine Weight & Volume: 24 Lbs & 2.91 Cbft
- Die Set Weight & Volume: 18 Lbs & 0.76 Cbft
- Warranty: 1 Year Manufacturer Warranty
